For use with monoball®Fix compatible tripod heads only - Our monoball®Fix camera plates are the perfect fit if you're looking for a modern solution that works well with mirrorless cameras, telephoto lens mounts, and accesories. Designed to be ultralight, compact, and multi-functional, these plates have a dovetail width of 26 mm, identical to ARCA-SWISS view camera monorails.

ARCA-SWISS monoball®Fix camera plates have a safety system that utilizes stop pins located in the monoball®Fix quick release channel. If the camera is tilted and the quick release is unlocked or loose, the safety pins will halt the movement, ensuring secure usage.

Please note: monoball®Fix is not compatible with "Arca style" quick releases from other brands.

When installing a monoballFix® camera plate to your camera for the first time, make sure to install the plate with wider lip overhanging the dovetail, oriented towards the locking mechanism side of the quick release. This is crucial since monoballFix® camera plates can only be mounted in one direction. Mount the camera to the quick release clamp, by tipping the short lip of the monoballFix® camera plate, into the lower channel of the quick release. Next, tip the oppsite side downwards to flatten and install the plate within the quick release.

It is important to ensure that the plate moves freely within the channel and comes to a stop at the safety pins located on either end of the channel. To securely fasten the plate in place, lock with either the screw knob or the lever locking mechanism, depending on the style of your quick release.

For a more detailed visual guide, please refer to the illustration below.
